Gmail

This document provides information on how to configure Gmail connection for Focus product.

https://docs.getvisibility.com/scan-with-getvisibility/configure-data-sources/gmail#create-oauth2-credentialsCreate OAuth2 Credentials

• Create a Project in Google Cloud Console:

  • Go to the Google Cloud Console

  • Create a new project or select an existing project



• Enable the Gmail:

  • In the Google Cloud Console, navigate to the "APIs & Services" > "Library"



  • Search for "Gmail API" and click on it



  • Click the "Enable" button to enable the Goolge Drive Activity API for your project

• Create OAuth 2.0 Credentials:

  • In the Google Cloud Console, navigate to the "APIs & Services" > "Credentials" tab



  • Click "Create credentials" and select "Service account"



  • Enter a name in the Service account name field and CREATE AND CONTINUE



  • Under Grant this service account access to the project, select role as Owner and click DONE



  • Select the newly created service account and click Keys > Add Key > Create new key



  • Make sure the key type is set to json and click Create



  • The new private key pair is generated and downloaded to the machine. Note the values of private_key, client_email and client_id

https://docs.getvisibility.com/scan-with-getvisibility/configure-data-sources/gmail#delegate-domain-wide-authority-to-your-service-accountDelegate domain-wide authority to your service account

• From your domain's Admin console, go to Main menu menu > Security > Access and data control > API controls

• In the Domain wide delegation pane, select Manage Domain Wide Delegation

• Click Add new

• In the Client ID field, enter the client ID obtained from the service account creation steps above

• In the OAuth Scopes field, enter a comma-delimited list of the scopes required for the application

• Use the below scopes:

  For scanning

  • https://www.googleapis.com/auth/admin.directory.user.readonly

  • https://www.googleapis.com/auth/gmail.readonly

  For tagging

  • https://www.googleapis.com/auth/gmail.modify

  • https://www.googleapis.com/auth/gmail.labels

  • https://www.googleapis.com/auth/gmail.metadata

• Click Authorize
